| รายละเอียดสินค้า |
Camera
| COMPONENT |
SPECIFICATION |
| Image Sensor |
1/1.8 type CMOS image sensor |
| Minimum Illumination |
Color : 0.04 lx (30IRE, F1.5, 1/30s)
Color : 0.06 lx (50IRE, F1.5, 1/30s)
BW : 0.03 lx (50IRE, F1.5, 1/30s)
BW : 0 lx (50IRE, F1.5,1/30s with IR LED) |
| White Balance |
ATW1/ ATW2/ AWC |
| Shutter Speed |
[30 fps/15 fps mode] 1/30 Fix to 1/10000 Fix
[25 fps/12.5 fps mode] 1/25 Fix to 1/10000 Fix |
| Intelligent Auto |
On / Off |
| Super Dynamic |
On / Off, The level can be set in the range of 0 to 31. |
| Dynamic Range |
Max. 132 dB (Super Dynamic : On, Level : 30 or more, 15fps) |
| Adaptive Black Stretch |
The level can be set in the range of 0 to 255. |
| Back Light Compensation/High Light Compensation |
BLC (Back light compensation) / HLC (High light compensation) / Off
(only when Super dynamic / Intelligent Auto : Off) |
| Fog Compensation |
On / Off (only when Intelligent auto / auto contrast adjust : Off) |
| Maximum Gain |
The level can be set in the range of 0 to 11. |
| Color/BW (ICR) |
Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) /
Auto2 (IR Light On) / Auto3 (SCC) |
| IR LED Light |
High / Middle / Low / Off,
Maximum irradiation distance : 70 m {Approx. 230 ft} (30IRE)
50 m {Approx. 164 ft} (50IRE) |
| Digital Noise Reduction |
The level can be set in the range of 0 to 255. |
| Video Motion Detection (VMD) |
On / Off, 4 areas available |
| Scene Change Detection (SCD) |
On / Off, 1 areas available |
| Audio Detection |
On / Off |
| AI Sound Classification |
Gunshot, Yell, Vehicle horn, Glass break |
| AI Analytics |
Yes |
| Privacy Zone |
On / Off, Up to 8 zones available |
| VIQS |
On / Off, Up to 8 zones available |
| Image Rotation |
0 ° / 90 ° / 180 ° / 270 ° |
| Camera Title (OSD) |
On / Off, Up to 40 characters (alphanumeric characters, marks) |
| Focus Adjustment |
Auto focus |
Lens
| COMPONENT |
SPECIFICATION |
| Optical zoom |
2.0x (Motorized zoom / Motorized focus) |
| Extra zoom |
2.0x - 6.0x (when resolution is 1280 x 720) |
| Focal length |
4.3 - 8.6 mm {5/32 inches - 11/32 inches} |
| Angular Field of View |
[16 : 9 mode]*[4:3 mode] is not supported.
Horizontal : 53° (TELE) – 104° (WIDE), Vertical : 30° (TELE) – 56° (WIDE) |
| Maximum Aperture Ratio |
1 : 1.5 (WIDE) – 1 : 2.4 (TELE) |
| Focus range |
1.0 m {39-3/8 inches} – ∞ |
DORI
| COMPONENT |
SPECIFICATION |
| Detect (25ppm / 8ppf) |
Wide: 60.0 m / 196.9 ft, Tele: 154.0 m / 505.4 ft |
| Observe (62.5ppm / 19ppf) |
Wide: 24.0 m / 78.7 ft, Tele: 61.6 m / 202.1 ft |
| Recognize (125ppm / 38ppf) |
Wide: 12.0 m / 39.4 ft, Tele: 30.8 m / 101.1 ft |
| Identify (250ppm / 76ppf) |
Wide: 6.0 m / 19.7 ft, Tele: 15.4 m / 50.5 ft |
System on Chip (SoC)
| COMPONENT |
SPECIFICATION |
| System on Chip (SoC) |
Ambarella CV22 |
Adjusting Angle
| COMPONENT |
SPECIFICATION |
| Ceiling mounting |
Horizontal : ±180 ° (PAN rotation part)
Vertical : 0 ° to 100 ° (TILT rotation part)
Yaw : –190 ° to +100 ° (YAW rotation part) |
| Wall mounting |
Horizontal : ±100 ° (TILT rotation part)*
Vertical : ±100 ° (TILT rotation part)*
Yaw : –190 ° to +100 ° (YAW rotation part)
* You can change between horizontal and vertical angels by adjusting the PAN rotation part. |
Browser GUI
| COMPONENT |
SPECIFICATION |
| Camera Control |
Brightness, AUX On / Off |
| Audio |
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High
Audio Output : On / Off Volume adjustment : Low / Middle / High |
| GUI / Setup Menu Language |
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Browser |
Microsoft Edge, Firefox, Google Chrome |
Network
| COMPONENT |
SPECIFICATION |
| Network IF |
10Base-T / 100Base-TX, RJ45 connector |
| Resolution H.265/ H.264/ JPEG (MJPEG) |
[16 : 9 mode (30 fps mode)][16 : 9 mode (25 fps mode)]
3840x2160/ 2560x1440/ 1920x1080/ 1280x720/ 640x360/ 320x180 |
| H.265/H.264 |
[Transmission Mode]
Constant bit rate / VBR / Frame rate / Best effort
[Transmission Type]
Unicast port (AUTO) / Unicast port (MANUAL) / Multicast |
| JPEG |
[Image Quality]
10 steps |
| Smart Coding |
GOP (Group of pictures control):
Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/
Advanced(Fixed GOP 60s w/1s key-frame)/
Frame rate control (Variable GOP 4s-16s with frame rate control)
*Advanced and Frame rate control are only available with H.265.
Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off |
| Audio Compression |
G.726 (ADPCM) : 16 kbps / 32 kbps
G.711 : 64 kbps
AAC-LC : 64 kbps / 96 kbps / 128 kbps |
| Audio Transmission Mode |
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Supported Protocol |
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3,
DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, SFTP, MQTT, LLDP
IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP,
SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP,
ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, SFTP, MQTT, LLDP |
| No. of Simultaneous Users |
Up to 14 users (Depends on network conditions) |
| Secure |
FIPS 140-2 level 3 Certified Secure Element (NXP® EdgeLock® SE050F), Device Certificate GlobalSign® pre-installed,
User authentication, Host authentication, HTTPS, 802.1X Support, Data encryption |
| SDXC/SDHC/SD Memory Card |
H.265 / H.264 recording :
Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure
JPEG recording :
Manual REC / Alarm REC (Pre/Post) / Backup upon network failure
Compatible SDXC/SDHC/SD Memory Card :
microSDXC memory card : 64 GB, 128 GB, 256 GB, 512 GB
microSDHC memory card : 4 GB, 8 GB, 16 GB, 32 GB
microSD memory card : 2 GB |
| Mobile Terminal Compatibility |
iPad, iPhone(iOS 8.0 or later), Android™ terminals |
| ONVIF® Profile |
G / M / S / T |
Alarm
| COMPONENT |
SPECIFICATION |
| Alarm Source |
3 terminals input, VMD alarm, Command alarm, Audio detection alarm |
| Alarm Actions |
SDXC/SDHC/SD memory recording, E-mail notification,
HTTP alarm notification Indication on browser, TCP alarm notification output |
Input/Output
| COMPONENT |
SPECIFICATION |
| Monitor Output (for Adjustment) |
VBS : 1.0 V [p-p] / 75 Ω, composite, Pin jack
An NTSC or PAL signal can be outputted from camera |
| Audio input |
ø3.5 mm stereo mini jack
For microphone input : Recommended applicable microphone : Plug-in power type
(Sensitivity of microphone : -51 dB to -38 dB (0 dB=1 V/Pa, 1 kHz))
Input impedance : Approx. 2 kΩ (unbalanced)
Supply voltage : 2.5 V ±0.5 V
For line input : Input level: Approx. –10 dBV |
| Audio Output |
ø3.5 mm stereo mini jack (monaural output)
Output impedance : Approx. 600 Ω (unbalanced)
Output level : –20 dBV |
| External I/O Terminals |
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)
ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1)
ALARM IN 3 (Alarm input 3/ AUX OUT) (x1) |
General
| COMPONENT |
SPECIFICATION |
| Safety |
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1 |
| EMC |
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035 |
| Power Source and Power Consumption |
DC power supply : DC12 V 1.0 A, Approx. 12.0 W
PoE (IEEE802.3af compliant) Device : DC48 V 240 mA, Approx. 11.5 W (Class 0 device) |
| Ambient Operating Temperature |
-40 °C to +60 °C (-40 °F to 140 °F)
(Power On range : –30 °C to +60 °C {–22 °F to +140 °F}) |
| Ambient Operating Humidity |
10 to 100 % (no condensation) |
| Anti-Condensation System |
Temish element + Heater + moisture absorption gel |
| Water and Dust Resistance |
IP66, IEC60529 measuring standard compatible, Type 4X(UL50E), NEMA 4X compliant |
| Shock Resistance |
IK10 (IEC 62262) |
| Dimensions |
ø133 mm (W) x 133 mm (H) x 383 mm (D)
{ø5-1/4 inches (W) x 5-1/4 inches (H) x 15-3/32 inches (D)} |
| Mass (approx.) |
Approx. 2.4 kg {5.3 lbs.} |
| Finish |
Main body : Aluminum die cast and resin, i-PRO white
Outer fixing screws : Stainless steel (Corrosion-resistant treatment)
Front panel : Polycarbonate resin, Clear (with ClearSight coating) |
| Other |
WV-S15700-V2LK : Heavy salt damage resistance specifications (ISO14993 compliant) |
AI Analytics applications
| COMPONENT |
SPECIFICATION |
| AI Video Motion Detection (AI-VMD) |
YES |
| AI Privacy Guard |
YES |
| AI Face Detection |
YES |
| AI People Detection |
YES |
| AI Vehicle Detection |
YES |
| AI Non mask Detection |
YES |
| AI Occupancy Detection |
YES |
|
