| Minimum Illumination |
Color : 0.09 lx, BW : 0.05 lx (F1.5, Maximum shutter : Off (1/30s), AGC : 11) BW : 0 lx (F1.5, Maximum shutter : Off (1/30 s), AGC : 11, when the IR LED is lit) Color : 0.006 lx, BW : 0.003 lx (F1.5, Maximum shutter : max. 16/30s, AGC : 11) *1 *1 Converted value |
| Image Sensor |
1/1.8 type CMOS image sensor |
| White Balance Function |
ATW1/ATW2/AWC |
| Shutter Speed |
1/30 Fix to 1/10000 Fix |
| AI Intelligent Auto |
On / Off |
| Super Dynamic |
On / Off, the level can be set in the range of 0 to 31. |
| Dynamic Range Stretch (DRS) |
Max. 132 dB (Super Dynamic : On, Level : 31) |
| Adaptive Black Stretch |
The level can be set in the range of 0 to 255. |
| Back Light Compensation/High Light Compensation |
BLC (Back light compensation) / HLC (High light compensation) / Off The level can be set in the range of 0 to 31. (only when Super dynamic / AI Intelligent Auto : Off) |
| Fog Compensation |
On / Off, The level can be set in the range of 0 to 8 (only when AI Intelligent auto / auto contrast adjust : Off) |
| Maximum Gain (AGC) |
The level can be set in the range of 0 to 11. |
| Color/BW (ICR) |
Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC) |
| IR LED Light (Optional) |
High / Middle / Low / Off, Maximum irradiation distance : 40 m {Approx. 131 ft} |
| Digital Noise Reduction (DNR) |
The level can be set in the range of 0 to 255. |
| Video Motion Detection (VMD) |
On / Off, 4 areas available |
| Scene Change Detection |
On / Off, 1 area available |
| Privacy Zone |
On / Off (up to 8 zones available) |
| Image Rotation |
0 ° (Off) / 90 °/ 180 ° (Upside-down)/ 270 ° |
| Camera Title (OSD) |
On / Off Up to 20 characters (alphanumeric characters, marks) |
| Optical Zoom |
2.0x (Motorized zoom / Motorized focus) |
| Extra optical zoom |
6.0x (when resolution is 1280x720) |
| Digital (Electronic) Zoom |
Choose from 3 levels of x1, x2, x4 |
| Focal Length |
4.3 mm - 8.6 mm {5/32 inches – 11/32 inches} |
| Maximum Aperture Ratio |
1 : 1.5 (WIDE) – 1 : 2.4 (TELE) |
| Focus Range |
1 m {39-3/8 inches} – ∞ |
| Angular Field of View |
[16 : 9 mode] *[4:3 mode] is not supported. Horizontal : 52° (TELE) – 101° (WIDE), Vertical: 29° (TELE) – 55° (WIDE) |
| Detect |
(25ppm / 8ft) Wide: 63.31 m / 207.71 ft, Tele: 157.46 m / 516.61 ft |
| Observe |
(62.5ppm / 19ft) Wide: 25.32 m / 83.08 ft, Tele: 62.99 m / 206.64 ft |
| Recognize |
(125ppm / 38ft) Wide: 12.66 m / 41.54 ft, Tele: 31.49 m / 103.32 ft |
| Identify |
(250ppm / 76ft) Wide: 6.33 m / 20.77 ft, Tele: 15.75 m / 51.66 ft |
| Adjusting Angle |
Horizontal (PAN) angle : ±180°, Vertical (TILT) angle : -30 to +85°, Azimuth (YAW) angle : ±100° |
| Camera Control |
Brightness, AUX On / Off |
| Audio |
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High Audio Output : On / Off Volume adjustment : Low / Middle / High |
| GUI / Setup Menu Language |
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Network IF |
10Base-T / 100Base-TX, RJ45 connector |
| Smart Coding |
Smart Facial Coding : On (Smart Facial Coding*) / On (Auto VIQS) / Off *Smart Facial Coding is only available with Stream(1). GOP (Group of pictures) control : On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off *On (Frame rate control) and On (Advanced) are only available with H.265 |
| Audio Compression |
G.726 (ADPCM) : 16 kbps / 32 kbps G.711 : 64 kbps AAC-LC*6 : 64 kbps / 96 kbps / 128 kbps *6 Transmission for 4 streams can be individually set. |
| Audio Transmission Mode |
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Supported Protocol |
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, FTP, SMTP, DNS, NTP, SNMP, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ |
| No. of Simultaneous Users |
Up to 14 users (Depends on network conditions) |
| SDXC/SDHC/SD Memory Card |
H.265 / H.264 recording : Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure JPEG recording : Manual REC / Alarm REC (Pre/Post) / Backup upon network failure Compatible SDXC/SDHC/SD Memory Card : Panasonic 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64 GB**, 128 GB**, 256 GB**model *SDHC card, ** SDXC card (except miniSD card and microSD card) *SDHC card, ** SDXC card (except miniSD card and microSD card) |
| Mobile Terminal Compatibility |
iPad, iPhone, AndroidTM terminals |
| ONVIF Profile |
G / S / M / T |
| Alarm Source (Alarm/Event) |
3 terminals input, VMD alarm, Command alarm |
| Alarm Actions |
SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification, Indication on browser, FTP image transfer, Panasonic alarm protocol output |
| Monitor Output (for Adjustment) |
VBS : 1.0 V [p-p] / 75 Ω, composite, ø3.5 mm mini jack An NTSC or PAL signal can be outputted from camera |
| Audio Input |
ø3.5 mm stereo mini jack |
| Audio Output |
ø3.5 mm stereo mini jack (Audio output is monaural.) Output impedance : Approx. 600 Ω (unbalanced) Output level : –20 dBV |
| External I/O Terminals (Cable) |
ALARM IN 1(Alarm input 1/ Black & white input/ Auto time adjustment input) (x1) ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1) , ALARM IN 3 (Alarm input 3/ AUX OUT) (x1) |
| Safety |
UL (UL60950-1), c-UL (CSA C22.2 No.60950-1), CE, IEC60950-1 |
| EMC |
FCC (Part15 ClassA), ICES003 ClassA, EN55032 ClassB, EN55024 |
| Power Source and Power Consumption |
DC power supply : DC 12 V 980 mA/Approx. 11.8 W PoE (IEEE802.3af compliant) Device : DC48 V 260 mA/ Approx. 12.5 W (Class 0 device |
| Ambient Operating Temperature |
-40 °C to +60 °C (-40 °F to +140 °F)*8 (Power On range : –30 °C to +60 °C {–22 °F to +140 °F}) *8 This camera is not equipped with the function to change the audio output to the monitor output. |
| Ambient Operating Humidity |
10 to 100 % (no condensation) |
| Water and Dust Resistance |
IP66 (IEC60529), Type 4X(UL50E), NEMA 4X compliant |
| Shock Resistance |
50J (IEC 60068-2-75 compliant), IK10 (IEC 62262) |
| Wind Resistance |
Up to 40 m/s {approx. 89 mph} |
| Dimensions |
When using base bracket : ø164 mm × 139 mm (H) {ø6-15/32 inches × 5-15/32 inches (H)} Dome radius 42 mm {1-21/32 inches} When using attachment plate only : ø154 mm × 103 mm (H) {ø6-1/16 inches × 4-1/16 inches (H)} Dome radius 42 mm {1-21/32 inches} |
| Mass |
When using base bracket : Approx. 1.6 kg {3.53 lbs} When using attachment plate only : Approx. 1.2 kg {2.65 lbs} |
| Finish |
Main body : Aluminum die cast, i-PRO white Outer fixing screws : Stainless steel (Corrosion-resistant treatment) Dome cover : Polycarbonate resin (with ClearSight coating), Clear |
